Deep Bass is achieved by focusing the speakers output to a lower frequency range than most conventional subwoofers.
A large 61.4 oz. magnet helps produce these powerful low frequencies.A newly incorporated 6- layer copper voice coil
with aluminum former, improves heat resistance. The air convection generated from the vibration of the diaphragm is
effectively used to cool the voice coil, contributing to the speakers power handling and ability to dissipate heat.
Features:
Cone Size: 30cm (12″)
Cone Type: PP Cone
Surround: Foam
Magnet: Ferrite Magnet
Frequency Response: 38 – 300Hz
Power Handling Capacity: 1800W
Power Handling Capacity: 350W
Impedance: 4 ohms
Sound Pressure Level: 82dB
Mass: 4.8kg (10.58 lbs)
Magnet Mass: 1740g (61.4 oz)
Mounting Depth: 157mm (6-3/16″)
Dimensions (WxHxD): 326mm x 326mm x 174.3mm
The new Graduated Pleat Damper helps prevent stress from affecting specific parts of the damper. This minimizes mechanical
damage and dramatically improves the damperÂ’s durability.
